Green Field Crystal Gateway

R.C.C Column Providing Up to Basement Level Using M20 Grade (2,4,6) Of Concrete (1’x9”) Column Footing Concrete Using M20 Grade And Normal Size Of The Footing Is (3’6”X3’6”) Column Reinforcement Using Fe 500 D -6nos-12#; Stirrups 8#6” C/C & Footing 10#6” C/C P.C.C (Plain Cement Concrete) Using C.M 1,5,10-6” Thick For Footing Only Plinth Beam Concrete Using M 20 Grade (2,4,6) (Cement , Sand Jelly) And General Size Of Beam (1’3”X9”) The Thickness Of The Lintel Concrete Various From (4..5” To 6” Thick) The Reinforcement Using Fe 500 D For Lintel & Plinth Beams Height Of The Roof Slab Concrete Is 10’ Feet From The Finished Floor Level (FFL) Roof Slab Concrete Using M 20 Grade ( 2,4,6 ) Grade For 5” Thick & Size Of The Beam Various From (1’6”X1’) Brick Work Using C.M 1,6 (Cement , Sand) For 9” Wall Thickness And Partition Wall (4.5”Tk) Using C.M 1,4 (Cement , Sand) All Structural Designed As Per Relavant IS codes and Engineer Will Responsible Designed Part Only.

As stated by the builder; shown as filed.
