IMC Nilgiri Parisar

Water Storage Tank(Capacity) • Two no of R.C.C. Underground water tank of capacity of 4.50.lacs liters each. • Two no of R.C.C. overhead water tank in each block. Water Supply Line Specifications • For Main Pipe Line-HDPE Pipes • For Supply of building blocks from main line -

CPVC

Pipes • R.C.C underground water tank • R.C.C head of tanks at terrace • Pumping arrangement External Electrification Details • Transformer has been proposed based on load capacity for no of blocks. • Power supply from transformer to blocks has been proposed through underground cables for each block. • 1x40/22watt florescent fitting street light has been provided on 9 mt steel tubular poles along the road for proper illumination through under ground cable with timer for switching on and off the lighting automatically. • Provision has been made for earthing of transformer, distribution electrical panel and street lighting by providing suitable size of earthing strips and

G I.

earthing plate as per standards. • Provision has been made for suitable capacity of DG set backup for lift, Parking and passage . Sewage And Disposal STP Details • Underground Pipe of R.C.C. NP2 • pipe Brick Masonry chambers with C.I./RCC cover • Provision of Sewerage treatment plant of required capacity Boundary Wall Details • RCC framed structure with brick work and required finishing, painting Boundary wall of 1.50 m high with brick m at required locations.
