S R Constructions Shree Chintamani Nagar

Structure

R. C. C.

structure in M25 concrete. Brick Work All Outer walls of building will be in AEC blocks or 6” thick fly ash brick masonary and inner walls in 4” thick. Plaster – Outer plaster will be sand faced plaster with best quality paint. Inside plaster will be plain neeru finish with oil bound distemper colorings. Floor – All rooms with 2’x2’ vitrified tiles with same skirting and all toilets with ceramic tiles. Price range 345 t0 360 Per Sq mtr. Dado – For toilet 7” white glazed tiles and 4” in Kitchen. Doors – All doors will be flush doors with necessary thickness with concrete frames. Main door will be provided with peep hole and safety chain. Windows – Aluminum windows of good sections will be provided with clear glass and safety grill. Kitchen – Kitchen will be fitted with Granite steel gray platform of 27” width and 8” long. Water Tank – One

R. C. C.

overhead tank and underground water tank will be constructed with water pump attached. Lift – Lift of any make brand

OTIS / KONE

with Power backup. Electricity 1) Concealed electrification with 2 Points and plug in each room. 2) 1 Point in each balcony. 3) 1 Point in each bath and

W. C.

4) 1 Point on wash basin. Sanitation 1) Orissa Pan 20” in each flat with one tap and flush tank. Make bell / Haindware / Parry ware. 2) Brass oxidized bib cock ½” for kitchen and one in bathroom. Make Plumber / Jaqwar. 3) 12”x18” wash basin for each flat. Make bell / Haindware / Parry ware.
